Moving Head Light Ultra Bright Rainbow Lighting Effect Beam and Pattern Light

Basic Info.

Model NO.	YH -GS 340
Control Channel	16CH
Strobe	Adjustable Speed Strobe
Control Mode	Dmx Signal Control
IP Rating	IP20
Certification	CE, RoHS
Voltage	AC90-264V, 50/60Hz
Net Weight	45kgs
Gross Weight (Carton)	18kgs
Power	3710W
Dimming	0-100% Linear Dimming.
Green Power	LED/Laser
Scan X:540°	16 Bit Precision Scany270
Packing Size (Carton): 500*450*720mm	500*450*720mm
Prism 1	32 Facet Prism
Wlight Source Life	≥3000hours
Color Temperature	7500ke(CCT)
Transport Package	Carton
Specification	500*450*720mm
Trademark	MXT
Origin	Guangdong
Production Capacity	500000

Product Description

Color temperature:7500K
Light source life:≥3000hours Scan
X:540°(16 bit precision scan) Y:270°(16 bit precision scan) Automatic error correction reset function Color system
1 color wheel: 14 color + white, half-color effect, rainbow effect with bidirectional rotation.
Gobo system

1. fixed pattern plate: 13 pattern pieces + white, with pattern dithering and pattern arbitrary positioning function.
2. Prism system Prism 1: 32 facet prism Prism 2: 8 facet prism
3. prisms can be stacked Effect

Frost effect+Rainbow effect Focusing angle:1.8° Automization: Independent automization
Dimming:0-100% linear dimming. Strobe: up to 25Hz, can choose random strobe or pulse strobe.
Environment
Working Temperature: -30-40 degree Cooling system: No noise fan
IP Grade: IP20 Display
Display: Rechargeable battery, you can enter the menu to set without powering on. The Chinese and English languages can be switched, and the display can be reversed 180°, which is convenient for hanging upside down. Reset detection: When there is no DMX signal, manual detection and automatic detection can be selected to facilitate inspection and maintenance. software
9 built-in programs to choose from Upgrade via DMX data cable
Can change the DMX address code from the console, remote control switch bulb, machine reset and other functions
Display lamp and light source usage time Channel: 16 channelsystemLight Source: 382W/311W/295W

Control High temperature automatic protection Standard DMX512 protocol

DMX shortcut interface RDM function Electrical parameters
Voltage: AC90-264V, 50/60Hz Power: 450W
Size and weight Packing size (carton): 500*450*720mm Net weight: 15kgs
Gross weight (carton): 18kgs

CH1	ch2	ch3	ch4	ch5	ch6	ch7	ch8
pan	pan fine	Tit	Tit fine	X/Y Speed	Dimmer	Strobe	Frost/Rainbow effect
ch9	ch10	ch11	ch12	ch13	ch14	ch15	ch16
Color Wheel	Gobo Wheel	Prism	Prism 1 rotating	Prism 2 rotating	Focus	Lamp control	Reset
