Professional LED Panel Light Full
Overview Product Description Adopting the cutting-edge intelligent color management system, ensuring precise color calib;
Overview
Adopting the cutting-edge intelligent color management system, ensuring precise color calibration and consistent output across different batches of lights;
With 40 built-in essential stage colors and special lighting effects available;Accurate CCT falling on the Planck curve, allowing adjustments from from 2800K to 10000K;Calibration of perfect greens/magenta in a range of full CCT;Precise control of every color based on the benchmark of CIE1931 color standard system, maintaining accuracy up to the third decimal place of XY values;Fixed luminance and other optical parameters when adjusting CCT;Fixed CCT and other optical parameters when adjusting luminance;Quick and simple upgrade of system software via USB or DMX interface;Alternative accessories such as cellular plate, shading shield, central bracket (magic legs), U-shaped bracket, etc.;
Allow battery-powered.
Detailed PhotosProduct Parameters
CertificationsPackaging & Shipping
Basic Info.
Model NO. | SG-L300-X |
Base Material | Metal |
Certification | CE, RoHS, ISO9001 |
Voltage | 220V |
Beam Angle | 120° |
Control Channel | 6CH |
Heat Dissipation | Ultra-Silent Smart Fan |
Control | DMX512 Signal, Rdm Signal, Manual Calibration |
Input Power | 250W |
Transport Package | Carton or Flighe Case |
Specification | 740 x 139 x 419mm |
Trademark | sigwon |
Origin | China |
HS Code | 5100 |
Production Capacity | 20000 Pieces/Year |
Product Description
Product DescriptionAdopting the cutting-edge intelligent color management system, ensuring precise color calibration and consistent output across different batches of lights;
With 40 built-in essential stage colors and special lighting effects available;Accurate CCT falling on the Planck curve, allowing adjustments from from 2800K to 10000K;Calibration of perfect greens/magenta in a range of full CCT;Precise control of every color based on the benchmark of CIE1931 color standard system, maintaining accuracy up to the third decimal place of XY values;Fixed luminance and other optical parameters when adjusting CCT;Fixed CCT and other optical parameters when adjusting luminance;Quick and simple upgrade of system software via USB or DMX interface;Alternative accessories such as cellular plate, shading shield, central bracket (magic legs), U-shaped bracket, etc.;
Allow battery-powered.
Detailed PhotosProduct Parameters
Optical Design | |
Light Source | RGBW 4-in-1 LED light source |
Number & Power of light sources | 952pcs × 0.8W |
Operating Lifespan | ≥50000 hours |
Color Temperature (CCT) | 3200K±150K/5600K±150K/2800K-6000K dynamically tunable (alternative) |
Color Rendering Index (CRI) | Ra≥92,TLCI≥97 |
Beam Angle | 120° |
Power Supply | |
Rated Voltage | AC100-240V / 50-60Hz |
Input power | 250W |
Battery power supply | DC48V |
Dimming & Control | |
Dimming | 0-100% smooth linear dimming |
Control | DMX512 signal, RDM signal, manual calibration |
Control Channels | 6CH |
Control Panel | LCD display screen + knob + button |
Features | |
Display | LCD displays the panel's CCT, luminance, and other parameters |
Heat dissipation | Ultra-silent smart fan |
Housing | Aluminum Profile |
Operating Environment | |
Temperature | -10°C ~ 40°C |
Humidity | 5% ~ 95% |
Dimensions & Weight | |
Dimensions | 740 x 139 x 419 mm (Length x Width x Height) |
Net/Gross Weight | 7.1kg/8.45kg |
Installation | |
Suspension | Standard hanging |
Safety | Safety: Secondary suspension with safety rope |
carton(single) or flight case(One pack of five)
Optional Accessories
