MPPT24z Solar Charge Controller LCD LED with RS485 Communication
MPPT24Z Solar Charge Controller LCD LED with RS485 Communication KEY FEATURES* LCD MPPT(Maximum Power Point Tracking) so;
Basic Info.
Model NO. | MPPT24Z |
Specification | MPPT24Z |
Trademark | Green Master / OEM |
Origin | Foshan, China |
HS Code | 9032899090 |
Production Capacity | 50000PCS/Year |
Product Description
MPPT24Z Solar Charge Controller LCD LED with RS485 CommunicationKEY FEATURES* LCD MPPT(Maximum Power Point Tracking) solar charge controller
* 12V/24V automatic recognition, Max PV input 100VDC or 150VDC
* LCD+LED Display the input and output parameter of PV and battery
* RS485 Communication For Operating and testing
* With DC Load port and also USB charger
* Three Stages charging, fast charge/Constant charge/Floating charging
* Vented, Sealed, Gel, NiCd battery or customer other battery selectable.
* User-Defined charge voltage by software
* With Temperature Compensation
Technical Specifications
Item | Model | MPPT24Z-15 | MPPT24Z-20 | MPPT24Z-30 | MPPT24Z-40 | MPPT24Z-50 | |
Output | System DC Voltage | DC12V/24V Automatic recognition | |||||
Output VDC Precision | ≤±1.5% | ||||||
Rated Output Current | 15A | 20A | 30A | 40A | 50A | ||
Current-limitingProtection | 20A | 25A | 35A | 45A | 55A | ||
Over ChargeProtection | yes. Difference for battery type difference | ||||||
Selectable battery | Sealed lead acid, vented, Gel, NiCd, or defined by user | ||||||
Temperature Compensation | 14.2V-(The highest temperature-25ºC)*0.3 | ||||||
USB ouput | 5V 3AMP | ||||||
Load output | Voltage | Follow the battery bank voltage | |||||
Current | 15A | 20A | 30A | 40A | 50A | ||
Input | Max PV voltage | 100VDC | 150VDC | ||||
12VDC Max PV input(W) | 200 | 260 | 390 | 520 | 650 | ||
24VDC Max PV input(W) | 400 | 520 | 780 | 1040 | 1300 | ||
Low Voltage InputProtection | higher 1 VDC than current bat VDC | ||||||
Overvoltage Protection | 100VDC | 150VDC | |||||
Overvoltage Recovery | 95VDC | 145VDC | |||||
Display | LED light display | select Confirm | |||||
LCD Display | Charge stage ,PV VDC AMP generated energy , Charger VDC AMP W, Bat Temp.Load VDC AMP discharge Energy. | ||||||
Communication | RS232 Communication by PC, | ||||||
Protection | Yes (PV Reverse connection, Battery Reverse connection, Over voltage, low voltage, over temperature, over load, Short circuit protection etc.) | ||||||
IP grade | IP30 | ||||||
Physical | Product size(D*W*H) | 200-110*66 | 243*155*79 | ||||
Package size (D*W*H) | 249*144*105 | 289*189*113 | |||||
G.N/N.G(kg) | 2/0.9KG | 2.5/1.8 |
PRODUCT
MPPT 12V 24VDC 15/20/30/40/50Amp Max PV Voltage 150V
LCD+LED Display input and output parameter of PV and battery
USB Charger 5V/3A Termp Sensor RS485 Communication
Why Choice us ?15 years Rich experience manufacturer, 8000 square meter,200 worker .15 Engineer keep to improve design and supply new products .7 QC to controller the Full process,100% inspection before shipment .TOP 5 manufacturer,Large batch production to guarantee competitive price. We are the only manufacturer who can sign "Quality Warranty"&"On Time Delivery Warranty" with client.One of the Few Supplier whom have factory to make the Key Products and also supply Complete set system design and installation supporting
Support OEM/ODM service with LOW MOQ!10 years experience in international bidding together with dealer.annually train to dealer office or in factory about design/installation and maintenanc
FAQ:
Are you factory or trade company?
we have two Factory in China. we make UPS/Inverter/Battery in Foshan city which is close to Guangzhou. We make Solar Panel in Ningbo city .
How to Collect the goods together from Two Factory
we will collect the goods together. the shipment from Ningbo or Guangzhou.
How can i get your pricelist?
Send an enquiry about what you need ,our sales will reply u within 12hours.
Can i get an sample to check quality before mass order? Welcome to place sample order to check our quality.
Any guarantee for your products?
one year or Two years for Electronic products and battery. 10 years For Solar panel. details we will promise in the Performa Invoice .
How about the delivery time?
Usually for sample order within one week, for mass order 10-30days
Do u support OEM/ODM service?
we have experienced R&D team, welcome to place OEM/ODM orders.
payment terms, any convenient and safe way for our buyers?
T/T,W/U or LC options. Your money will be in safe, your business will be in safe!
