Basic Info.

Model NO.	XMTG-608
Usage	Temperature Control
Control Method	Electronic Type
Transport Package	1PCS/Box
Specification	ISO 9001: 2008 Others
Trademark	CJ
Origin	China
HS Code	9032900090
Production Capacity	100000PCS/Year

Product Description

SpecificationsTemperature controllerOn/offPID controlTemperature meter are dual row 3-LED displayInput: CU50; PT100; J; E; K; T
XMT*608 series intelligent temperature controller, is double row 3-LED display and include on/off, PID control, including with parameter of self-setting function. This temperature meter respectively display temperature measurement value (PV) and temperature set value (SV) under normal mode; When it is time temperature control, respectively display temperature measurement value (PV) and running time count down (SV), and also provide kinds of time control method selection; The controller can input kinds of signal which are used interchangeably, it adopt ON/OFFP=0PID control, allowing an easy parameter setting and convenient inputting, is widely used over temperature automatic control systems of machinerychemicalceramicslight industrialmetallurgypetrifaction and heat treatment and so on.
Main technical Indexes
1, Measurement deviation: ± 0.5%F· S± 1B, Cold end compensating deviation≤ ± 2C
2, Input(can be selected): CU50(-50~150), PT100(-199~600), K(-30~999),
E(-30~700), J(-30~900), T(199~400)
3, Relay output contact capacity: AC220V 5A(resistance load)
Period 2~120s can be adjusted.
4, Drivng solid relay signal output: Driving electric current >15m A voltage >9V,
Period is 2S
5, Power: AC85V~242V, 50/60Hz
6, Work environment: Temperature 0~50.0C, relative humidity≤ 85%RH, without corrode and strong electric radiation.
Instrument panel(consult)

Connection scheme(consult)

Series		Code	Name	Setting range	Remark	Ex-Factory
First Menu	0	-	Appointed data	Determined by and	Press∧or∨for 3 second and set the temperature setting value you need	-
	1	AL	High/Low-limit alarm	Determined by and	-	Random
	2	SC	Measurement deviation	-20.0~20.0	Measuring value can be modified through increasing or decreasing this data.	0
	3	P	Proportion time	0~99.9~200	When the P↑,the proportion and differential function↓;If the P↓,the proportion and differential function↑ When P=0,the meter is ON/OFF control.	15.0
	4	I	Calculus time	0~999	It's used to adjust static difference. To increse it,the static difference will be reduced, but if it is too high, the static difference will drift instability.	240
	5	d	Differential time	0~200		30
	6	t	Control period	2~120S	When it leaves factory, SSR is 2s; Relay is 20s. When P=0, it makes no sense.	20
	7	Hy	Main control by drop in level	0.1~50.0	It only controls at ON/OFF	1.0
	8	At	Parameter setting itself	/	OFF_shut itself function ; ON_open itself function Select ' ON'only can adjust for one time,and then turn back to 'OFF '	OFF
	9	Loc	Electronics lock	0~50	Loc=0 all the parameter can be revised Loc=1 only the appointed data can be revised	0
Second Menu	10	Loc	Electronics lock	0~50	idem	0
	11	Sn	Input type	-	CU50\PT100\K\E\J(\T;	K
	12	dIL	Set lower limit	dIL≤dIH	CU50(-50~150)\ PT100(-80~600)\ K(-30~999)\E(-30~700)\ J(-30~900)\T(199~400)	0
	13	dIH	Set upper limit			400
	14	PF	Filt modulus	0~50	It is the software filter constant of measurement sampling.The constant ↑,the measurement antijamming capability↑,but the measurement speed and system response time ↓	20
	15	COL	System function choice	ON/OFF	ON:positive control(cooling control) OFF:reverse control(heating control)	OFF
